滲透檢測報告(首頁)
JUBANG QUALITY INSPECTION
Penetrating Checking Report
報告編號Report Number：JBZJUT-202004-020 第1頁 共6頁
工件名稱 artifact names | Double glass Sight flow indicator | 產品規格 Spec | 3/4", 1.5”, 2”, 3" | ||
委托單位 Customer | 檢測日期 Date for inspection | ||||
工件編號 Workpiece No | 1-36 | 工藝卡編號 Process card No | JBZJPT-201612-001 | ||
執行標準 Standard of inspection | NB/T47013.5-2015 | 驗收級別 Acceptance levels | Ⅰ | 檢測比例 Detection numbers | 100% |
材 質 Material of sample | SS316L | 規 格 Spec | 見續頁 see appendix | 檢測時機 Detection time | 焊后 After welding |
焊條牌號 Electrode material | ER316L | 表面狀態 Surface?condition | 外觀檢查合格 Qualified | 工件表面溫度 surface temperature | 20℃ |
檢測方法 test method | ⅡC-d | 檢測面 Detection surface | 外表面 External surface | 觀察方法 Observation method | 目視 visual |
試塊 Test block
| B型試塊 Type B test block | 對比試驗 contrast test | / | 靈敏度等級 Sensitivity class | 3級 class 3 |
滲透劑型號 Penetrant model | DPT-5 | 清洗劑型號 Detergent model | DPT-5 | 顯像劑型號 Developer model | DPT-5 |
滲透時間 Penetration time | 10 min | 干燥時間 Drying time | 5 min | 顯像時間 Developing time | 10 min |
可見光照度 Visible illuminance | ≥1000lx | 黑光照度 Black light illuminance | / | 去除多余滲透劑 Remove excess penetrant | 擦拭 wipe |
滲透檢測報告(首頁)
Penetrating Checking Report
報告編號Report Number： 第2頁 共6頁
滲透劑施加方法 penetrating Agent Adding Ways | 噴 Ways Of Spraying | 顯像劑施加方法 Method of applying developer | 噴 Ways Of Spraying | 干燥狀態 Drying State | 自然干燥 Dry naturally | ||
檢測結論Test Summary：
本報告對所委托焊縫進行滲透檢測，質量符合 NB/T47013.5-2015標準（I級）的要求，滿足產品合格級別II級要求，檢驗結論合格。 In this report, the welds entrusted by the entrusting party are subject to penetrant inspection, and the quality meets the requirements of NB/T47013.5-2015 standard (level I), the product qualification level II, and the inspection conclusion is qualified.
| |||||||
檢測人（資格）inspector： 年 月 日 | 審核人（資格）auditor： 年 月 日 | 無損檢測專用章NDT Special seal for inspection： | |||||
滲透檢測報告(續頁)
Penetrating Checking Report(appendix)
報告編號Report Number：
序號 No. | 規 格 Spec mm | 檢測部位 Examination region | 檢測長度 Checking?Part mm | 缺陷的定性、定量及定位 Qualitative, quantitative and positioning of defects | 評定等級 Rating |
1. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
2. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
3. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
4. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
5. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
6. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
7. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
8. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
9. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
10. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
11. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
12. | 3/4" | 焊縫 weld | 552.64 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
13. | 1.5" | 焊縫 weld | 960.84 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
14. | 1.5" | 焊縫 weld | 960.84 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
15. | 1.5" | 焊縫 weld | 960.84 | 未發現相關缺陷顯示 No relevant defects found | Ⅰ |
